HOLEMAKER HMPRO36AD - Page 19

HM PRO 36 AD
ITEM
PART NUMBER
DESCRIPTION
Q-TY
7
KOL-0521-08-01-00-0
GEAR z63
1
8
LOZ-000100
BALL BEARING 30x42x7
1
9
PRS-000021
EXTERNAL RETAINING RING 30z TYPE A
1
10
SPR-000063
DISC SPRING fi27.99xfi21.74x0.3
1
11
WLK-0521-07-00-00-0
PINION SHAFT z16 z32 ASSY
1
12
LOZ-000038
BALL BEARING 12x28x8
2
13
PDK-000221
WASHER 20x28x0.1
2
14
PDK-0521-13-00-00-0
SETTING WASHER
1
15
SLN-0521-03-00-00-1
MOTOR ASSY - 120V
1
15
SLN-0521-03-00-00-3
MOTOR ASSY - 230V
1
16
NSD-000009
HANDLE COVER
1
17
UCW-0521-12-00-00-0
HANDLE
1
18
WKR-000101
HEX SOCKET BUTTON HEAD SCREW M6x16
2
19
PDK-000021
ROUND WASHER 6.4
4
20
PRS-000019
EXTERNAL RETAINING RING 28z
2
21
PRS-000259
SEAL 20x28x4
1
22
TLJ-000010
SELF-LUBRICATING SLEEVE 28.05x32x1
2
23
KRP-0521-01-01-00-1
BODY
1
24
WLK-0521-10-00-00-0
FEED SHAFT z20
1
25
WKR-000302
SELF-TAPPING SCREW 5x30
4
26
WKR-000395
HEX SOCKET ROUND HEAD SCREW WITH FLANGE M5x20
2
27
PDK-000151
NYLON WASHER 8.1x14x3
4
28
OSL-0521-09-01-00-0
CHIP GUARD
1
29
SPR-000030
SPRING 1x10x17.5
2
30
ZSP-0521-04-00-00-0
QUILL ASSY
1
31
PRS-000011
EXTERNAL RETAINING RING 20z
1
32
TLJ-0521-04-01-00-0
QUILL CARRIER
1
33
LOZ-000045
BALL BEARING 20x42x12
1
34
PRS-000026
INTERNAL RETAINING RING 42w
1
35
WRZ-0378-03-02-00-0
SPINDLE
1
36
WKR-000063
HEX SOCKET SET SCREW WITH FLAT POINT M8x8
2
37
SPR-0378-03-04-00-0
SPRING
1
38
WYP-0378-03-05-00-0
PLUNGER
1
39
PDK-0139-00-04-00-0
WASHER 18.8x10x1
1
40
PRS-000009
INTERNAL RETAINING RING 19w
1
41
PDS-0521-14-00-00-0
ELECTROMAGNETIC BASE ASSY
1
42
LOZ-000072
BALL BEARING 9x26x8
1
43
WLK-0521-06-00-00-0
PINION SHAFT z11 z26 ASSY
1
44
STR-0521-05-00-00-0
ELECTRONIC CONTROLLER ASSY – 120V
1
44
STR-0521-05-00-01-0
ELECTRONIC CONTROLLER ASSY – 230V (CEE)
1
44
STR-0521-05-00-02-0
ELECTRONIC CONTROLLER ASSY – 230V (AU)
1
44
STR-0521-05-00-03-0
ELECTRONIC CONTROLLER ASSY – 230V (INDIA)
1
45
SZN-0075-00-51-00-5
POWER CORD 120V 3x2.08 WITH STRAIN RELIEF ASSY (US)
1
45
SZN-0212-10-02-00-2
POWER CORD 230V 3x1.5 WITH STRAIN RELIEF ASSY (CEE)
1
45
SZN-0212-10-02-00-1
POWER CORD 230V 3x1 WITH STRAIN RELIEF ASSY (AU)
1
45
PWD-0212-10-02-00-6
POWER CORD 230V 3x1.5 WITH STRAIN RELIEF ASSY (INDIA)
1
46
DLW-000007
CABLE GLAND WITH STRAIN RELIEF PG11
1
47
WKR-000420
COUNTERSUNK HEAD SCREW M3x16
1
48
OBD-0521-05-01-00-0
ELECTRONIC CONTROLLER HOUSING
1
49
WKR-000208
PAN HEAD SCREW M4x10
1
50
PDK-000060
EXTERNAL TOOTH LOCK WASHER 4.3
1
51
NKR-000013
HEX NUT M4
1
