HMPRO36AD OPERATOR’S MANUAL
www.holemaker.com
3
CONTENTS
1. GENERAL INFORMATION 3
1.1. Application 3
1.2. Technical data 3
1.3. Equipment included 4
1.4. Dimensions 5
1.5. Design 5
2. SAFETY PRECAUTIONS 6
3. STARTUP AND OPERATION 7
3.1. Installing and removing the handle 7
3.2. Installing, removing, and operating the annular cutter 8
3.3. Preparing 10
3.4. Drilling 12
3.5. Replacing the motor brushes 13
4. WIRING DIAGRAM 15
PRO 36 AD
1. GENERAL INFORMATION
1.1. Application
The PRO 36 AD is a drilling machine with electromagnetic base, designed to drill
holes with
diameters of up to 36 mm (1-7/16’’) either to a depth of up to 20 mm
(13/16’’) by using HSS annular cutters or to a depth of up to 30 mm (1-3/16’’) by using
TCT annular cutters. When using twist drill bits with a 19 mm (3/4’’) Weldon shank you
can
drill holes with diameters of up to 12 mm (1/2’’) to a depth of up to 20 mm
(13/16’’).
The electromagnetic base
allows the drilling machine to be fixed to ferromagnetic
surfaces with a force that ensures operator safety and proper machine operation.
A safety strap protects the machine from falling in case of a power loss.
With an optional HSS quill assembly you can drill holes to a depth of up to 25 mm
(1’’) by using HSS cutters or twist drill bits with a 19 mm Weldon shank.
1.2. Technical data
Voltage
1~ 110–120 V, 50–60 Hz
1~ 220–240 V, 50–60 Hz
Total power 1000 W
Motor power 920 W
Tool holder 19 mm (3/4’’) Weldon
Maximum drilling diameter with annular cutter 36 mm (1-7/16’’)
Maximum drilling diameter with twist drill bit 12 mm (1/2’’)
Maximum drilling depth with HSS cutter or drill bit 20 mm (13/16’’)*
Maximum drilling depth with TCT cutter 30 mm (1-3/16’’)
Electromagnetic base holding force
(surface with the thickness of 25 mm and roughness R
a
= 1.25)
8 900 N
Electromagnetic base dimensions
90 mm × 180 mm × 38.5 mm
3-9/16’’ × 7-1/16’’ × 1-1/2’’
Stroke 39 mm (1-1/2’’)
Rotational speed without load
550 rpm (for 115 V)
580 rpm (for 230 V)
Rotational speed under load
350 rpm (for 115 V)
370 rpm (for 230 V)
Minimum workpiece thickness 6 mm (1/4’’)
Protection class I
Noise level More than 85 dB
Required ambient temperature 0–40°C (32–104°F)
Weight 9.5 kg (21 lbs)
* Up to 25 mm (1’’) when used with an optional HSS quill assembly (ZSP-0521-04-00-00-0).
