HOLOPLOT X1 User Manual

41X1 MD80-S Manual 1.0 en
Data Sheet
AMPLIFICATION
Type
Max. Output Power
4
5x 16-channel digital amplier modules
1x single-channel digital subwoofer amplier module with differential pressure sensor
and onboard zero-latency-DSP enabling adaptive closed-loop processing of the
subwoofer driver signal
Sub: 8,500 Wpk
LF: 16x 500 Wpk
HF: 64x 240 Wpk
PROCESSING
Type
DSP Channels
Computation
High-performance Field Programmable Gate Array (FPGA) computing the HOLOPLOT
proprietary digital signal processing algorithms for 3D Audio-Beamforming and Wave
Field Synthesis
Dual-core ARM® Cortex™-A9 running HOLOPLOT OS, a Linux-based, distributed
audio operating system
80 + 1
7600 parametric EQ bands and more than 1100 Finite Impulse Response (FIR) lters
with over 430000 lter taps
Sleep Mode
Idle
Continuous
Max Power
POWER CONSUMPTION
140 W
400 W
1,040 W
1,710 W
Control/Audio
Power
CONNECTORS ON LOUDSPEAKER CABINET FOR SUBWOOFER MODULE
1x etherCON Cat 6A (RJ45) for SubLink
1x Amphenol HP-3-MDQ for AC Power IN (115 - 240 V AC, 50 - 60 Hz)
Control/Audio
Power
CONNECTORS ON ELECTRONICS PACKAGE
4x etherCON Cat 6A (RJ45) for Control and Audio-over-IP (Dante™, AES67)
2x etherCON Cat 6A (RJ45) for HoloLink
2x etherCON Cat 6A (RJ45) for SubLink
1x Amphenol HP-3-MDQ for AC Power IN (115 - 240 V AC, 50 - 60 Hz)
1x Amphenol HP-3-MDGQ for AC Power OUT (208 - 240 V AC, 50 - 60 Hz)
4
Peak power based on the maximum
unclipped voltage the amplier will produce
into the nominal load impedance
