42X1 MD80-S Manual 1.0 en
MECHANICAL DETAILS
All measurements given in mm
Data Sheet
PHYSICAL CHARACTERISTICS
Dimensions
Weight
800 mm x 600 mm x 981 mm (±2.5 mm)
160 kg
Loudspeaker Cabinet - front
Loudspeaker Cabinet - rear
Electronics Package
Protective Grille
MATERIALS AND COLOURS
Glass ber-reinforced polycarbonate, ame retardant, textured black nish (RAL 9005)
Premium multi-ply Finnish Birch Plywood, Polyurea nish, textured black (RAL 9005)
Aluminum alloy, powder-coated black (RAL 9005)
Hexagon-perforated steel with hydrophobic, damp, and dust repellent acoustic cloth,
black (RAL 9005)
Device Condition
Packaged in shipping box
Operating
ENVIRONMENTAL CONDITIONS
Temperature
-20 °C to +60 °C
+10 °C to +45 °C
Humidity
to 90% at +60 °C
to 70% at +45° C
(non-condensing)
Altitude
to 12,000 m MSL
to 2,000 m MSL
FRONT
800
600
SIDE
981
TOP
166 815
577
BACK
