Homelite HCS5150C User Manual

23
Deutsch (Übersetzung der originalen Anleitungen)
23
English (Original instructions)
WARNING
To avoid serious personal injury, do not attempt
to use this product until you read thoroughly and
understand completely the operator’s manual. If you
do not understand the warnings and instructions in
the operator’s manual, do not use this product. Call
Homelitecustomerserviceforassistance.
WARNING
The operation of anypower toolcan result inforeign
objectsbeingthrowninto youreyes,whichcanresult
in severe eye damage. Before beginning power tool
operation,alwayswearsafetygogglesorsafetyglasses
withsideshieldsand,whenneeded,afullfaceshield.
We recommend Wide Vision Safety Mask for use
over eyeglasses or standardsafety glasseswith side
shields.Alwaysuseeyeprotectionwhichismarkedto
complywithEN166.
WARNING
Long term inhalation of the engine's exhaust fumes,
chain oil mist and sawdust can result in serious
personalinjury.
Savetheseinstructionsandpassthemonifthesawisto
beusedbyanotherperson.
SPECIFICATIONS
Modelname HCS5150C
Description 51cc50cm(20'')CEsaw
Weight-nobar,chain,fuel 5.3kg
Fueltankcapacity 575cm
3
Lubricanttankcapacity 350cm
3
Barlength 50cm
Usablecuttinglength 48.5cm
Chainpitch 8.26mm(0.325inch)
Chaingauge 1.27mm(0.05inch)
Chaintype
0.325"lowprolefull
complement
Drivesprocket 7teethx0.325''
Enginedisplacement 51cm
3
Maximumenginepower(ISO
7293)
2.0kW
Recommendedmaximumengine
speedwithcuttingattachment
11,500r/min
Recommendedenginespeed
atidling
2,600-3,600r/min
Specicfuelconsumptionat
maximumenginepower
490g/kwh
Soundpressurelevel(ISO22868)
LpAav:100dB(A),KpA=3
dB(A)
Soundpowerlevel(ISO22868) 114dB(A)
Vibration(ISO22867): Carlton/Oregon
– Fronthandle 8.12m/s
2
,K=1.5
– Rearhandle 8.0m/s
2
,K=1.5
Bar & Chain (Carlton guide bar only use with
Carlton saw chain, and Oregon guide bar only use
with Oregon saw chain)
Guidebar(nosilkscreen)
– Carltonpartnumber 200PXBK041
– Partnumber 308112001
– Color Black
Chain
– Oregonpartnumber 20BPX-78
– Partnumber 900920005
DESCRIPTION
1. Fronthandguard/Chainbrake
2. Fronthandle
3. Enginecover
4. Primerbulb
5. Chokelever
6. Chain
7. Startergrip
8. Guidebar
9. Chaincatcher
10.Triggerrelease
11.Chainlubricantcap
12.Silencer
13.Carburettoradjustment
14.Rearhandle
15.Throttletrigger
16.Fuelmixcap
17.On/Offswitch
18.Starter/Fanhousing
19.Spikedbumper
OPERATION
Foryoursafety,studythisentiremanualbeforeoperating
thesaw. Payparticular attentionto theprecautions and
instructionslistedintheoperator’smanual.
