Homelite HG5700 Series Replacement Parts List

3
HOMELITE GENERATOR − HG5700 SERIES
PARTS LIST
The model number will be found on a plate attached to the engine. Always mention the model number in all correspondence regarding your GENERATOR
or when ordering replacement parts.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 310227003 Generator Head Assembly (Inc. Key Nos. 2 & 4-12) ....... 1
2 640331002 Adapter Housing .............................................................1
3 660596002 Bolt, Wiz (3/8-18 x 1-1/4 in.) ...........................................4
4 661557003 Bolt (5/16-24 x 6-5/8 in., Hex Hd.) ..................................1
5 638678002 Lock Washer (5/16 in.). ....................................................3
6 290441001 Brush Assembly ..............................................................1
7 660596009 Bolt, Stator 5.7kW ........................................................... 4
8 519785002 Brush Cover ....................................................................1
9 638703001 Ground Lug .....................................................................1
10 661603002 Bolt, Mounting Brush Assembly ......................................1
11 661603001 Bolt, Mounting AVR ......................................................... 2
12 290440002 Automatic Voltage Regulator ..........................................1
13 570356001 Isolator ............................................................................4
14 660591006 Bolt (5/16-18 x 1 1/2 in., Hex Hd.) ..................................4
15 678659001 Lock Nut (3/8-16) ............................................................2
16 638386003 Washer, Flat (3/8 in.) ........................................................ 4
17 310223001 Wheel (10 in.) ...................................................................2
18 638498001 Wheel Spacer .................................................................. 2
19 661558002 Bolt (3/8-16 x 4-1/4 in.) ...................................................2
20 310222002 Frame Assembly .............................................................1
21 678145002 Flange Nut (5/16-18) .......................................................7
22 678655001 Cord Retainer ..................................................................2
23 660598001 Screw (6-20 x .38 in.) ......................................................4
24 290403002 Wire Panel .......................................................................1
25 760504002 Switch, Engine Stop ........................................................ 1
26 290400001 Recepticle (120 V, 20 Amp) .............................................2
27 780350001 Circuit Breaker 20 Amp Single Pole ................................ 2
28 290401001 Recepticle (240 V, 30 Amp) .............................................1
29 780351003 Circuit Breaker 25 Amp Single Pole ................................ 1
30 661503005 Bolt (1/4-20 x 1 in) ........................................................... 2
31 678259003 Lock Nut (5/16-18) ..........................................................4
32 310224006 Handle Assembly (Inc. Key No. 58) .................................1
33 570355001 Rubber Foot ....................................................................2
34 661503003 Bolt (1/4-20 x 1/2 in.) .......................................................2
35 638706001 Front Foot Bracket ..........................................................1
36 638675004 Washer (5/16 in.) .............................................................2
37 660599001 Bolt (5/16-18 x 1 in. Hex Hd.) ..........................................2
38 678656001 Nut, Nyloc (1/4-20) .......................................................... 2
39 638387002 Washer (1/4 in.) ...............................................................2
40 310715001 Lanyard ...........................................................................2
41 310712001 Handle Lock Pin .............................................................. 2
42 519728001 Handle Bracket Spacer ...................................................2
43 Note A Engine (Yamaha OHV) .....................................................1
44 570358001 Fuel Line Assembly (Incl. Key No. 59) ............................. 1
45 519711001 Fuel Shut Off with Filter ................................................... 1
46 661603001 Bolt .................................................................................. 2
47 519709001 Fuel Cap .......................................................................... 1
48 310711004 Fuel Tank Assembly .......................................................1
49 661503005 Screw (1/4-20 x 1 in.) ......................................................4
50 638497001 Heat Shield ...................................................................... 1
51 661502005 Bolt (5/16-18 x 3/4 in., Hex. Hd.) ....................................1
52 290404001 Ground Wire Assembly ...................................................1
53 638704001 Washer (5/16 in.) External Star ........................................2
54 638499002 Gasket ............................................................................ 1
55 678654001 Nut (8 mm) .......................................................................2
56 309322002 Muffler ............................................................................1
57 660599002 Bolt (5/16-24 x 5/8 in.) .....................................................2
58 570357001 Handle Grip .....................................................................2
59 678408005 Fuel Line Clamp ..............................................................2
NOT SHOWN:
901606006 Lubricant (SAE 10W30) ...................................................1
940971018 Caution/Danger Hang Tag ...............................................1
940974007 Risk of Fire Danger Label ................................................ 1
940513010 Ground Label ..................................................................1
940513008 Ground Warning Label ....................................................1
940680015 Hot Surface Label ...........................................................1
940514001 Lock Pin Label .................................................................1
940752004 Logo Label ......................................................................1
940708007 Engine Lubricant Label ...................................................1
940617033 Quick Start Label ............................................................1
940617023 Starting Label .................................................................. 1
987000481 Operator’s Manual ...........................................................1
KEY PART
NO. NUMBER DESCRIPTION QTY.
NOTE A: Homelite Consumer Products, Inc., will not provide engines as replacement parts.
Engines are covered through the engine manufacturer’s warranty. Consult the accompanying
engine manual or contact our service department for assistance.
WARNING:
To avoid possible personal injury or equipment damage, a registered electrician or an authorized
service representative should perform installation and all service. Under no circumstances should
an unqualified person attempt to wire into a utility circuit.
