REPLACING THE PRO CUT I STRING
HEAD
1. Turn off the product.
2. Loosen the spool retainer by turning it
counterclockwise and then remove the
string head.
3. Take a new PRO-CUT I string head and
a 0.5 meter length of 2.4 mm diameter
monolament pre-cut line. Place the
middle of the line under the hook/notch
inside the spool. Feed the ends of the
line through the eyelets on the side of
the PRO-CUT I xed line head.
4. Pull the line outwards so it is tight and
even on both sides of the spool. Install
the PRO-CUT I head assembly on the
drive shaft and then secure with spool
retainer.
