Homelite UT20006 User Manual

5
HOMELITE 25cc STRING TRIMMER – MODEL NOS. UT20006, UT20026, AND UT20046
REPLACEMENT PARTS – FIGURE B
29 300753003 STARTER HOUSING ASSEMBLY ........................... 1
30 638033001 SPRING AND CONTAINER ....................................
1
31 518098001 STARTER PULLEY .................................................. 1
32 900849002 STARTER ROPE .....................................................
1
33 511731001 STARTER GRIP .......................................................
1
34 638032001 BAFFLE .................................................................. 1
35 638094001 HEAT SHIELD .........................................................
1
36 660694001 * SCREW (8-16 X 1/2
in. THREAD FORMING) ......... 3
37 660629001 * SCREW (10-14 X 3/4 in. THREAD FORMING) ....... 2
38 518106001 REAR HOUSING .....................................................
1
39 660630002 * SCREW (10-24 X 3/4
in. TRUSS HD.) .................... 3
40 900994006 MUFFLER GASKET ................................................ 1
41 308092008 CATALYTIC MUFFLER ASSEMBLY
(INCL. KEY NO. 50 THRU 52) ................................. 1
42 900999002 GASKET ................................................................. 1
43 660638003 * SCREW (10-24 X 2-3/16
in. TORX HD. ) ................ 2
44 678138003 PISTON RING .........................................................
1
45 308457001 PISTON ASSEMBLY
(INCLUDES KEY NO. 44) ........................................
1
46
660870001 * SCREW (6-20 X 1/4 in. PAN HD.) ........................... 3
47 638044001 OUTLET TUBE ........................................................ 1
48
638268001 SCREEN ................................................................. 1
49 300753005 COMPLETE STARTER ASSEMBLY ........................
1
50 660616001 * SCREW (10-24 X 7/8 in. TORX HD.) ....................... 1
51 640070002 CYLINDER ..............................................................
1
52 900953001 CYLINDER GASKET ...............................................
1
53 660342002 SCREW (M5 X 20 mm) ........................................... 3
983000857 OPERATOR'S MANUAL
983000857R REPAIR SHEET (REV:03)
05-03-06
1 308455001 SHORT BLOCK ASSEMBLY
(EXTERNAL GASKETS NOT INCLUDED) ...............
1
2 660661001 CARBURETOR BOLTS ...........................................
2
3 900994008 INTAKE GASKET ....................................................
1
4 660662001 * SCREW (10-24 X 1-1/16
in. PAN HD.) .................... 2
5 900740001 CARBURETOR GASKET ........................................
1
6 518070001 HEAT DAM ..............................................................
1
7 678027001 * LOCK NUT (10-24) .................................................
2
8 900952001 AIR FILTER .............................................................
1
9 518094001 AIR FILTER BOX .....................................................
1
10 518096001 AIR BOX COVER ....................................................
1
11 308054003 CABURETOR ASSEMBLY ......................................
1
12 518105001 BUTTON SWITCH ..................................................
1
13 T660619001 SCREW, (6-19 X 1/2
in. T.F.) ................................... 1
14 678032002 COMPRESSION SPRING .......................................
1
15 308055002 THROTTLE CABLE W/HANGER ............................
1
16 570549001 BUMPER ................................................................
1
17 308181004 FUEL TANK (INC. KEY NO. 22) ..............................
1
18 900954001 CRANK CASE COVER GASKET ............................
1
19 660638004 * SCREW (10-24 X 3/4 in. PAN HD. TORX W/LW) ...............
4
20 638092001 DRIVE CONNECTOR ..............................................
1
21 631049001 FLAT WASHER .......................................................
1
22 300758006 FUEL CAP ASSEMBLY ...........................................
1
23 570256001 BUMPER ................................................................
2
24 290218001 LEAD W/TERMINALS .............................................
1
25 660660001 * SCREW (8-32 X 1
in. THREAD FORMING) ........... 2
26 308064001 IGNITION MODULE ................................................
1
27 870170001 SPARK PLUG (CHAMPION RCJ4) .........................
1
28 300952002 ROTOR AND PAWL ASSEMBLY ............................
1
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
** STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
