1 000998228 STRAIGHT SHAFT ASSEMBLY (INC. LABEL) ..............................................1
2 308454001 GRASS SHIELD ASSEMBLY (INC. HARDWARE) .........................................1
3 660641001 * SCREW (10-24 x 5/8 in.) ...............................................................................1
4 660642001 * SCREW (1/4-20 x 1-1/4 in.) ...........................................................................1
5 308053004 GEAR HEAD ..................................................................................................1
6 678011002 WASHER .......................................................................................................1
7 678019002 SHAFT ADAPTER .........................................................................................1
8 308042003 SPOOL RETAINER (LH) ................................................................................1
9 660857001 SCREW, SQUARE HEAD ..............................................................................1
10 638020001 CUT OFF BLADE ..........................................................................................1
11 660675001 SCREW .........................................................................................................2
12 678246001 WING NUT ....................................................................................................1
13 638225001 SHIELD CLAMP ............................................................................................1
14 518328001 GRASS SHIELD ............................................................................................1
15 678022001 SPRING .........................................................................................................1
16 308044002 SPOOL & STRING (.080 in.) ..........................................................................1
17 000998230 COMPLETE STRING HEAD (.080 in.) (INC. KEY NOS. 8, 15, AND 16) ........1
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
** STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
REPLACEMENT PARTS
FIGURE C
HOMELITE 25cc STRING TRIMMER – MODEL NO. UT20046
7

Homelite UT20006 Specifications

General

Brand	Homelite
Model	UT20006
Category	Trimmer
Language	English
