Page 11 – English
1
2
EXPLODED VIEW AND PARTS LIST
The model number will be found on a plate attached to the engine housing. Always mention the model number
in all correspondence regarding your HEDGE TRIMMER or when ordering replacement parts.
PARTS LIST
1 34201162G * Deflector Retainer ......................................................................................................1
2 3401162G * Clipping Deflector ......................................................................................................1
987000229 Operator’s Manual
KEY PART
NO. NUMBER DESCRIPTION QTY
* For Use With Model UT44120 Only
