Homematic IP HmIP-FCI6 User Manual

40
General information about radio operation
Hereby, eQ-3 AG, Maiburger Str. 29, 26789 Leer/
Germany declares that the radio equipment type
Homematic IP HmIP-FCI6 is in compliance with Directive
2014/53/EU. The full text of the EU declaration of
conformity is available at the following internet address:
www.eq-3.com
12 Technical specifications
Device short name: HmIP-FCI6
Supply voltage: 2x 1.5 V LR03/micro/
battery
Standby power consumption: 10 µA
Current consumption: 40 mA max.
Battery life: 3 years (typ.)
Degree of protection: IP20
Ambient temperature: 5 to 35 °C
Dimensions (W x H x D): 48.5 x 53 x 15 mm
Weight: 50 g (incl. batteries)
Radio frequency band: 868.0-868.6 MHz
869.4-869.65 MHz
Maximum radiated power: 10 dBm
Receiver category: SRD category 2
Typ. open area RF range: 230 m
Duty cycle: < 1 % per h/< 10 % per h
Subject to technical changes.
