Homematic IP HmIP-PSM-2 User Manual

42
Technical specifications
12 Technical specifications
Device short description: HmIP-PSM-2
Supply voltage: 230 V/50 Hz
Current consumption: 13 A max.
Standby power consumption: < 0.3 W
Max. switching capacity: 3 kW
Kind of load: ohmic load, cosφ≥0.95
Life expectancy relay/
switching cycle: 40000 (13 A, ohmic load)
Relay: NO contact, 1-pole, µ
contact
Switch type: independently mounted
switch
Operating mode: S1
Withstand voltage: 2500 V
Protection class: I
Method of operation: Type 1
Degree of protection: IP20
Ambient temperature: -10 to +35 °C
Degree of pollution: 2
Dimensions (W x H x D): 70 x 70 x 39 mm
(not incl. mains plug)
Weight: 154 g
Radio frequency band: 868.0–868.6 MHz
869.4–869.65 MHz
Maximum radiated power: 10 dBm
Receiver category: SRD category 2
Typ. open area RF range: 400 m

Homematic IP HmIP-PSM-2 Specifications

General

Brand	Homematic IP
Model	HmIP-PSM-2
Category	Switch
Language	English
