The humidifier is equipped with a removable cassette in which a matrix and
LegioSafe filter are fitted. The matrix cannot be cleaned. The humidifier
cassette must be replaced at least every year to guarantee safe and
healthy humidification. A service message is triggered that is visible by a
LED coming on (next to the lock symbol) at the bottom of the humidifier.
8.1 Procedure for replacing cassette
1. Remove the plug from the socket.
2. Disconnect the water supply.
3. Make sure that the drain hose is free and can move with the movement that is necessary to gain access to the
top.
4. Make sure that the water supply hose has sufficient room to move with it, or disconnect from the tap.
5. Undo the screws on the side of the brackets so that the humidifier can be turned in the bracket. Use a
crosshead 2 or 3 screwdriver.
6. Turn the humidifier 90° so that the cassette is accessible. Take into account any leakage water from the side
of the unit!
7. Disconnect the cassette from the water supply by pushing in the ring of the knee joint (on side of the housing)
and sliding the whole knee off of the black hose. In this way the cassette is disconnected and can be
removed.
8. Pull/slide the cassette out of the humidifier.
For this use the tool supplied with it or water pump pliers!
9. Clean the inside of humidifier with a soft cloth if necessary.
Do NOT use a cleaning product!
10. Remove the new cassette from the packaging.
11. Push/slide this into the unit.
12. Push the black hose of the new cassette into the knee joint.
13. Turn the humidifier again such that it hangs level.
14. Tighten the brackets.
15. Open the water supply duct
16. Insert the plug into the socket.
17. Your humidifier is again safe, reliable and ready for a new period!
NB: The whole used cassette can be disposed of with the residual waste.
