Section 6 – Installation
The direct connection must be made to a water extraction point fitted in accordance with NEN6526.
The HomEvap Direct consists of 3 modules;
1. HomEvap Humidifier - This is the EPP unit with 2 times around 200 connections and contains the matrix. At the
bottom is a cord with a plug, 1 shc80 duct sensor cord, 1 connection cord to Fan box. 50cm 16mm drain hose, 1.5m
4mm water inlet hose (black)
2. The fan box - This is the EPP unit with 2 times around 200 connection and contains the fan. At the bottom there is a
cord with a plug which is connected to the power cord of the HE humidifier. Use the supplied splitter for this.
3. The control panel - This is the controller which is equipped with an internal moisture and temperature sensor.
The wireless control has its own user manual.
ATTENTION the control panel and humidifier are UNIQUE linked together make sure they do not get
exchanged. !!!!
6.1 Order of operation
NOTE: The units must be level!
Physical suspension
1. Determine the location of the Direct in the home. For optimum efficiency the Direct should be installed in a place
where the exiting air can easily flow through the house. E.g. hall, attic in staircase, closet in kitchen or storage room to
large living room.
2. Determine whether the units can be installed freely together, connected to a piece of hose, or coupled with a pitch
ring r200.
3. The HE is equipped with a mounting bracket with an m8 threaded bush. This can be used for suspension via a
threaded rod.
4. Free space around should be such that the humidifier is too horizontal to turn during a service.
Water connection
5. Connect the black 4 mm hose with the ¾ adapter to the water supply connection of the water supply via a washing
machine tap ¾ bu wire with check valve.
Ensure that the water pressure is between 1.5 bar and max. 5 bar.
Water drain connection
6. The HE is supplied with a 16mm drain hose on a compression fitting.
This should be connected with the sewerage in an odorless manner.
ATTENTION the water consumption is a maximum of 1ltr/min. In the event of a line break in the appliance, normal use
max. 2 l / h min. drain 25mm.
Duct humidity and temperature sensor
Mount the SHC80 sensor directly into the air supply channel after the HE.
CAUTION that the sensor is not damaged!
