4. Diagram of the C12 Controls
① Large Rotary Knob
② Alarm Set Button
③ Mode Selector and On/Off Knob
④ Small Knob
⑤ USB Charging Port 1
⑥ USB Charging Port 2
⑦ DC Adaptor Socket
⑧ AUX-in Jack
⑨ Celsius/Fahrenheit Selector Switch
⑩ Temperature sensor
24hr/12hr Mode Selector Switch
Time Set Switch
Alarm Source Selector Switch
Alarm Volume Control
④ ③ ② ①
⑦ ⑧ ⑨
⑩
Antenna
－3－
① ② ③ ④
⑤ ⑥
Insert the SD
card into the
SD card slot
to play the
stored musics.
