Front Side Cowls
The front side cowls must be removed for the
headlight bulb, front turn signal light bulbs
and position light bulbs replacement.
The left and right front side cowls can be
removed in the same manner.
❙
Removal
1.
Remove the inner cover. 2 P. 59
2.
Remove the bolt, clips A and clip B.
2 P. 63
3.
Remove the prongs from the grommets,
then remove the front side cowl.
❙
Installation
Install the parts in the reverse order of
removal.
