Storing Your Motorcycle
If you store your motorcycle outdoors, you
should consider using a full-body motorcycle
cover.
If you won't be riding for an extended period,
follow these guidelines:
● Wash your motorcycle and wax all painted
surfaces (except mat painted surfaces). Coat
chrome pieces with rust-inhibiting oil.
● Lubricate the drive chain. 2 P. 51
● Place your motorcycle on its centre stand
and position a block so that both tyres are
off the ground.
● After rain, remove the body cover and allow
the motorcycle to dry.
● Remove the battery (2 P. 58) to prevent
discharge. Charge the battery in a shaded,
well-ventilated area.
u If you leave the battery in place,
disconnect the negative - terminal to
prevent discharge.
After removing your motorcycle from storage,
inspect all maintenance items required by the
Maintenance Schedule.
Transporting Your
Motorcycle
If your motorcycle needs to be transported, it
should be carried on a motorcycle trailer or a
flatbed truck or trailer that has a loading ramp
or lifting platform, and motorcycle tie-down
straps. Never try to tow your motorcycle with a
wheel or wheels on the ground.
NOTICE
Towing your motorcycle can cause serious
damage to the transmission.
20170224170119_32MGC6510_eng_BOOK Page 123 Friday, February 24 2017 17:08:26 JST
Storing Your Motorcycle
Information
120

Honda CB1100CA 2017 Specifications

General

Camshaft	DOHC
Displacement	1140 cc
Bore x Stroke	73.5 mm x 67.2 mm
Compression Ratio	9.5:1
Fuel System	PGM-FI electronic fuel injection
Transmission	6-speed
Final Drive	Chain
ABS	Yes
Seat Height	795 mm
Curb Weight	252 kg
Engine Type	Air-cooled 4-stroke DOHC inline-four
Front Suspension	Telescopic fork
Rear Suspension	Twin shock
Rear Brakes	Single 256 mm disc
Tires Front	110/80R18
Tires Rear	140/70-17
Fuel Capacity	14.6 litres
Valves	16
Power	66kW (90PS) @ 7, 500rpm
Front Brakes	Dual 296 mm floating discs, 4-piston calipers
