Honda CB1100CA 2017 User Manual

Importance of Maintenance ........................... P. 42
Maintenance Schedule
..................................... P. 43
Maintenance Fundamentals ...........................P. 46
Tool Kit................................................................. P. 57
Removing & Installing Body Components..P. 58
Battery.................................................................... P. 58
Clip.......................................................................... P. 60
Seat .........................................................................P. 61
Side Cover.............................................................P. 62
Spark Plug ...........................................................P. 63
Engine Oil ............................................................P. 65
Air Cleaner........................................................... P. 69
Brakes................................................................... P. 71
Side Stand ........................................................... P. 74
Drive Chain..........................................................P. 75
Clutch ...................................................................P. 81
Throttle ................................................................ P. 82
Crankcase Breather ........................................... P. 83
Other Adjustments............................................ P. 84
Adjusting the Headlight Aim ............................ P. 84
Adjusting the Clutch and Brake Levers .......... P. 85
Adjusting the Front Suspension....................... P. 86
Adjusting the Rear Suspension ........................ P. 87
20170224170119_32MGC6510_eng_BOOK Page 44 Friday, February 24 2017 17:08:26 JST
Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully
before attempting any maintenance. Refer to “Specifications” for service data.
Maintenance

Honda CB1100CA 2017 Specifications

General

Camshaft	DOHC
Displacement	1140 cc
Bore x Stroke	73.5 mm x 67.2 mm
Compression Ratio	9.5:1
Fuel System	PGM-FI electronic fuel injection
Transmission	6-speed
Final Drive	Chain
ABS	Yes
Seat Height	795 mm
Curb Weight	252 kg
Engine Type	Air-cooled 4-stroke DOHC inline-four
Front Suspension	Telescopic fork
Rear Suspension	Twin shock
Rear Brakes	Single 256 mm disc
Tires Front	110/80R18
Tires Rear	140/70-17
Fuel Capacity	14.6 litres
Valves	16
Power	66kW (90PS) @ 7, 500rpm
Front Brakes	Dual 296 mm floating discs, 4-piston calipers
