■ Bulbs
Headlight LED
Brake/Tail light LED
Front turn signal lights
CB1100CA 12 V-21 W × 2
CB1100NA LED
Rear turn signal lights
CB1100CA 12 V-21 W × 2
CB1100NA LED
■ Fuses
Main fuse 30 A
Other fuses 30 A, 20 A, 10 A
■ Torque Specifications
Oil filter 26 N·m (2.7 kgf·m, 19 lbf·ft)
Engine oil drain bolt 30 N·m (3.1 kgf·m, 22 lbf·ft)
Rear wheel axle nut
CB1100CA 93 N·m (9.5 kgf·m, 69 lbf·ft)
CB1100NA 113 N·m (11.5 kgf·m, 83 lbf·ft)
Front wheel axle blot 59 N·m (6.0 kgf·m, 44 lbf·ft)
Front wheel brake
caliper mounting
bolts
CB1100CA 31 N·m (3.2 kgf·m, 23 lbf·ft)
CB1100NA 45 N·m (4.6 kgf·m, 33 lbf·ft)
Front wheel axle
pinch bolt
CB1100CA 26 N·m (2.7 kgf·m, 19 lbf·ft)
CB1100NA 22 N·m (2.2 kgf·m, 16 lbf·ft)
20170224170119_32MGC6510_eng_BOOK Page 130 Friday, February 24 2017 17:08:26 JST
Specifications
Specifications
127

Honda CB1100CA 2017 Specifications

General

Camshaft	DOHC
Displacement	1140 cc
Bore x Stroke	73.5 mm x 67.2 mm
Compression Ratio	9.5:1
Fuel System	PGM-FI electronic fuel injection
Transmission	6-speed
Final Drive	Chain
ABS	Yes
Seat Height	795 mm
Curb Weight	252 kg
Engine Type	Air-cooled 4-stroke DOHC inline-four
Front Suspension	Telescopic fork
Rear Suspension	Twin shock
Rear Brakes	Single 256 mm disc
Tires Front	110/80R18
Tires Rear	140/70-17
Fuel Capacity	14.6 litres
Valves	16
Power	66kW (90PS) @ 7, 500rpm
Front Brakes	Dual 296 mm floating discs, 4-piston calipers
