Honda CR85 2006 User Manual

106 Technical Information
Vehicle Identification
Serial Numbers
The VIN, frame and engine serial numbers are
required when you register your CR. They may
also be required when ordering replacement
parts. You may record these
numbers in the Quick Reference section at the
rear of the manual.
The frame number (1) is stamped on the right
side of the steering head.
RIGHT SIDE
(1) frame number
The engine number (2) is stamped on the left
crankcase.
LEFT SIDE
(2) engine number
(1)
(2)
CR85R/105-13005.6.82:29PM ページ 106

Honda CR85 2006 Specifications

General

Displacement	84.7 cc
Bore x Stroke	47.5 mm x 47.8 mm
Compression Ratio	8.4:1
Ignition	CDI
Transmission	6-speed
Final Drive	Chain
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	70/100-17
Rear Tire	90/100-14
Engine Type	Single-cylinder, two-stroke
Front Suspension	Telescopic fork
Rear Suspension	Swingarm with single shock
Fuel Capacity	1.3 gallons
Dry Weight	140 lbs
