95
SIDE STAND
Refer to the Safety Precautions on page 55.
Check the side stand spring (1) for damage
and loss of tension, and the side stand
assembly for freedom of movement.
If the side stand is squeaky or stiff, clean
the pivot area and lubricate the pivot bolt
with clean engine oil.
(1) Side stand spring
(1)
37K28B31.book Page 95 Monday, July 26, 2021 6:11 PM

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda CRF125FB 2021 and is the answer not in the manual?

Honda CRF125FB 2021 Specifications

General IconGeneral
Engine Type124cc air-cooled single-cylinder four-stroke
Bore and Stroke52.4mm x 57.9mm
Compression Ratio9.0:1
IgnitionCDI
TransmissionFour-speed
Final DriveChain
Rear BrakeDrum
Front Tire70/100-19
Rear Tire90/100-16
Wheelbase49.4 inches
Seat Height30.9 inches
Fuel Capacity1.0 gallon
Valve TrainSOHC; two-valve
StarterElectric
Front Suspension31mm telescopic fork; 5.9 inches of travel
Rear Suspension5.9 inches of travel
Front Brake220mm hydraulic disc
