61
AIR CLEANER
Refer to the Safety Precautions on page 55.
The air cleaner should be serviced at
regular intervals (page 57). Service more
frequently when riding in unusually wet or
dusty areas.
1. Remove the left side cover (page 41).
2. Unlatch the retainer clips (1), and
remove the air cleaner housing cover(2).
3. Unhook the set spring (3), take care to
avoid bending the set spring and set
spring holder (4).
4. Remove the air cleaner (5).
(1) Retainer clips (2) Air cleaner housing cover
(3) Set spring
(4) Set spring holder
(5) Air cleaner
