42
SEAT
The seat (1) must be removed for battery
and main fuse maintenance.
Removal:
1. Remove the bolts (2) and collars (3).
2. Remove the seat backward.
Installation:
1. Insert the front recess (4) into the front
prong (5) and the rear prong (6) into the
rear recess (7).
2. Install the collars onto the bolts. Tighten
the bolts securely.
(1) Seat
(2) Bolts
(3) Collars
(4) Front recess
(5) Front prong
(6) Rear prong
(7) Rear recess
(4)
(3)
(1)
(2)
(5)
(6)
(2)
(7)
