Honda Element 2004 - Under-Hood Fuse Box

WWW.MANUALS.WS
WWW.MANUALS.WS
−
−
−
No. Circuits ProtectedAmps.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Condenser Fan
Small Light
Interior Light
Cooling Fan Motor
Hazard
IGP
Horn, Stop
Not Used
Back Up
ABS Motor
Rear Defroster
Heater Motor
Power Window
Option
Left Headlight
Door Lock
Right Headlight
ABSF/S
Battery
Ignition 1
Spare Fuses
30 A
15 A
7.5 A
20 A
15 A
15 A
15 A
10 A
30 A
20 A
40 A
40 A
40 A
15 A
15 A
15 A
30 A
100 A
50 A
21 25 7.5A 30A
Fuse Locations
Taking Care of the Unexpected
200
UNDER-HOOD FUSE BOX
