Both seats can be removed to give
more cargo capacity. To remove a
seat:
Pull the release strap on the seat
support to unlock the seat support.
Remove the cover betweenthe
seat cushion and the side wall by
pulling the tab and pulling the
cover straight up.
Push the lock lever forward to
unlock the seat.
1.
3.2.
CONTINUED
Removing the Rear Seats
Seats
Instruments and Controls
79
RELEASE STRAP
COVER
TAB
LOCK LEVER
STEEL HANDLE
