14
CONTROLS & FEATURES
CONTROLS
Choke Knob
Fuel Valve Lever
OFF
CCLLOOSSEEDD
OOPPEENN
OONN
CHOKE KNOB
FUEL VALVE LEVER
The OPEN position provides the
correct fuel mixture for operation
after starting, and for restarting a
warm engine.
The CLOSED position enriches
the fuel mixture for starting a cold
engine.
The choke knob opens and closes
the choke valve in the carburetor.
The fuel valve lever is located
between the fuel tank and
carburetor.
After stopping the engine, turn
the fuel valve lever to the OFF
position.
The fuel valve lever must be in the
ON position for the engine to run.
11/12/06 12:53:14 42Z26700_016
