SERVICING YOUR GENERATOR

7. Use a brush to remove carbon deposits from the spark arrester screen.

Be careful to avoid damaging the screen.

The spark arrester must be free of breaks and holes. Replace the spark arrester

if it is damaged.

8. Install the spark arrester and the exhaust tail pipe in the reverse order of

removal.

9. Install the lower muffler protector, the rear under plate, and the rear handle in

the reverse order of removal.

Install the lower muffler protector inside the hook securely.

LOWER

MUFFLER

PROTECTOR

HOOK

REAR UNDER

PLATE

REAR HANDLE

LOWER MUFFLER PROTECTOR

31ZS96101.book 57 ページ２０２０年２月２６日　水曜日　午後２時３３分
