OPERATION
AC Receptacle Selection
The generator has separate main power producing circuits. These two
circuits supply power to different receptacles shown when the voltage
selector switch is in the 120/240 V position.
When two or more receptacles are used, prevent overloading by
dividing the load between the two power circuits.
The chart below shows the rated load in amperes that can be
connected to each receptacle to balance the generator when the 120/
240 V locking plug receptacle is used for 120 V.
The total rated ampere draw is:
45.8 A
Main power circuit
Main Circuit I
Main Circuit II
Receptacles powered
by each main circuit
1, 3 and 4
2and5
Power distribution
1 3 4=22.9A rated.
2 5=22.9A rated.
06/09/12 12:22:50 31Z25600_037

Honda EU6500is Specifications

General

Model	EU6500is
Category	Portable Generator
Rated Voltage	120/240V
Rated Amperage	45.8/22.9A
Inverter	Yes
Electric Start	Yes
Displacement	389cc
Starting System	Electric and Recoil
Fuel Type	Gasoline
Rated AC Output	5500W
Engine	Honda GX390
Fuel Tank Capacity	4.5 gal
Run Time per Tankful at 1/4 Load	14.0 hrs
DC Output	12V, 8A
Noise Level	60 dB(A)
Engine Type	4-stroke, OHV
Outlets	Two 120V 20A GFCI Duplex, One 120/240V 30A Locking Plug
