Honda EU6500is User Manual

×
×
54
SERVICING YOUR GENERATOR
SPARK ARRESTER SERVICE
SPARK ARRESTER
5 14 mm PAN HEAD SCREW (2)
Install the spark arrester in the reverse order of removal.
The spark arrester must be free of breaks and holes. Replace the
spark arrester if it is damaged.
Be careful to avoid damaging the screen.
Use a brush to remove carbon deposits from the spark arrester
screen.
The spark arrester must be serviced every 100 hours to keep it
functioning as designed.
If the engine has been running, the muffler will be very hot. Allow the
muffler to cool before servicing the spark arrester.
Remove the two 5 14 mm pan head screws, and remove the spark
arrester.
1.
2.
3.
06/09/12 12:25:48 31Z25600_055

Honda EU6500is Specifications

General

Model	EU6500is
Category	Portable Generator
Rated Voltage	120/240V
Rated Amperage	45.8/22.9A
Inverter	Yes
Electric Start	Yes
Displacement	389cc
Starting System	Electric and Recoil
Fuel Type	Gasoline
Rated AC Output	5500W
Engine	Honda GX390
Fuel Tank Capacity	4.5 gal
Run Time per Tankful at 1/4 Load	14.0 hrs
DC Output	12V, 8A
Noise Level	60 dB(A)
Engine Type	4-stroke, OHV
Outlets	Two 120V 20A GFCI Duplex, One 120/240V 30A Locking Plug
