41
3.Air cleaner service
A dirty air cleaner will restrict air flow to the carburetor. To prevent
carburetor malfunction, service the air cleaner regularly. Service more
frequently when operating the engine in extremely dusty areas.
Never use gasoline or low flash point solvents for cleaning the air
cleaner element. A fire or explosion could result.
CAUTION:
Never run the engine without the air cleaner. Rapid engine wear will
result.
1.Unlock the cover lock using a screwdriver or similar tool, and open
the engine upper cover.
2.Remove the cover nut and the air cleaner cover. Remove the
elements and separate them. Carefully check both elements for holes
or tears and replace if damaged.
COVER
LOCK
ENGINE UPPER COVER
LOCK
UNLOCK
FOAM ELEMENT
PAPER ELEMENT
AIR CLEANER
COVER
COVER NUT
