Honda MSX125SF 2017 User Manual

51
Maintenance
Engine Oil
Checking the Engine Oil
1. If the engine is cold, idle the engine for 3
to 5 minutes.
2. Turn the ignition switch off and wait for 2
to 3 minutes.
3. Place your motorcycle in an upright
position on a firm, level surface.
4. Remove the oil fill cap/dipstick and wipe it
clean.
5. Insert the oil fill cap/dipstick until it seats,
but don’t screw it in.
6. Check that the oil level is between the
upper level and lower level marks in the oil
fill cap/dipstick.
7. Securely install the oil fill cap/dipstick.
Oil fill cap/dipstick
Upper
level
Lower
level
17 MSX125 (LO CA)-32K26D200.book 51 ページ ２０１７年２月１４日 火曜日 午前１０時２２分

Honda MSX125SF 2017 Specifications

General

Fuel System	PGM-FI electronic fuel injection
Transmission	4-speed
Front Suspension	Inverted telescopic fork
Rear Suspension	Monoshock
Front Tire	120/70-12
Rear Tire	130/70-12
Seat Height	765 mm
Fuel Tank Capacity	5.5 liters
Curb Weight	107 kg
Bore x Stroke	52.4 mm x 57.9 mm
Compression Ratio	9.3:1
Starter	Electric
Final Drive	Chain
Engine Type	Air-cooled, 4-stroke, single cylinder
Front Brake	Single 220mm disc with two-piston caliper
Rear Brake	Single 190mm disc with single-piston caliper
Dry Weight	101.7 kg
Max Torque	11 Nm (8.1 lb-ft) @ 5250 rpm
Wheelbase	1200mm
