62
Maintenance
Clutch
Checking the Clutch
❙
Checking the Clutch Lever Freeplay
Check the clutch lever freeplay.
Check the clutch cable for kinks or signs of
wear. If necessary have it replaced by your
dealer.
Lubricate the clutch cable with a
commercially available cable lubricant to
prevent premature wear and corrosion.
Freeplay at the clutch lever:
10 to 20 mm (0.4 to 0.8 in)
Freeplay
Clutch lever
NOTICE
Improper freeplay adjustment can cause premature clutch
wear.
17 MSX125 (LO CA)-32K26D200.book 62 ページ ２０１７年２月１４日 火曜日 午前１０時２２分

Honda MSX125SF 2017 Specifications

General

Fuel System	PGM-FI electronic fuel injection
Transmission	4-speed
Front Suspension	Inverted telescopic fork
Rear Suspension	Monoshock
Front Tire	120/70-12
Rear Tire	130/70-12
Seat Height	765 mm
Fuel Tank Capacity	5.5 liters
Curb Weight	107 kg
Bore x Stroke	52.4 mm x 57.9 mm
Compression Ratio	9.3:1
Starter	Electric
Final Drive	Chain
Engine Type	Air-cooled, 4-stroke, single cylinder
Front Brake	Single 220mm disc with two-piston caliper
Rear Brake	Single 190mm disc with single-piston caliper
Dry Weight	101.7 kg
Max Torque	11 Nm (8.1 lb-ft) @ 5250 rpm
Wheelbase	1200mm
