6.
Support your motorcycle securely and
raise the front wheel off the ground using
a maintenance stand or a hoist.
7.
Loosen the left axle pinch bolts.
8.
On the left side, withdraw the front axle
shaft, and remove the side collars and
wheel.
Installation
1.
Attach the side collars to the wheel.
2.
On the left side, place the wheel between
the fork legs and insert the lightly greased
front axle shaft to the end, through the
left fork leg and wheel hub.
3.
Align the end of the front axle shaft with
the surface of the fork leg.
Tire Puncture u Removing Wheels
Troubleshooting
115
Continued
Axle pinch bolts
Front axle shaftSide collar
End of front axle
shaft
Surface of fork reg
To Next Page
