Honda NM4 2018 - Right under Cowl

Right Under Cowl
#
Removal
1. Remove the upper hook on the right
under cowl from the slot on the engine
cover.
2. Remove the prongs from the grommets.
3. Remove the lower hook on the right
under cowl from the slot.
4. Remove the right under cowl.
#
Installation
1. Insert the lower hook on the right under
cowl to the slot.
2. Align the prongs with the grommets.
3. Push the prongs in.
4. Insert the upper hook on the right under
cowl to the slot on the engine cover until
it latches.
Removing & Installing Body Components u Right Under Cowl
Maintenance
82
Grommets Prong
Upper
hook
Lower hookRight under cowl
Prong
