Honda NM4 2018 - Front Lower Cover

Front Lower Cover
#
Removal
1. Remove the right and left side panels.
2 P. 80
2.
Remove the clips. 2 P. 77
3. Remove the bolts.
4. Remove the front lower cover.
#
Installation
Install the parts in the reverse order of
removal.
Removing & Installing Body Components u Front Lower Cover
Maintenance
78
Clips
Bolts
Bolt
Front lower cover
Clips
