Left side
1.
Remove the bolts A.
2.
Remove the left side duct panel.
3.
Remove the bolts B.
4.
Remove the prongs from the grommets.
5.
Remove the hooks.
6.
Remove the left side panel.
#
Installation
Install the parts in the reverse order of
removal.
Removing & Installing Body Components u Side Panel
Maintenance
81
Bolts A Left side duct panel
Left side panel
Prong
Hook
Bolts B Grommet
To Next Page
