Rear seat horizontal position
adjustment
Rear seat can be adjusted forward and
backward using the hex wrench in the tool
kit.
a
Adjust the rear seat to the upright position.
(P.52)
b
Remove the bolts A and remove the rear
seat cover.
c
While pulling the ratchet plate cover toward
rear, remove the rear hook and lift the cover
up.
d
Tip the rear seat back in some degree. Slide
the ratchet plate cover forward and remove
the front hooks, then lift it up.
Operation Guide
53
Continued
Bolts A
Rear seat cover
Front hooks
Ratchet plate cover
Rear hook
To Next Page
