Honda ST1100 1996+ User Manual

- Copyright for this owners manual only ©2011 LIFRASCHAL -
29
Essential Individual Components
IGNITION SWITCH
The ignition switch is on the handlebar cover.
Key Position Function Key Key Removal
ON
All electrical circuits are on. Engine and lights can be
operated.
Key cannot be
removed.
OFF
All electrical circuits are off. (Except for Digital clock)
Engine cannot be started.
Key can be
removed.
LOCK (steering
lock)
Steering is locked. Engine and lights cannot be
operated.
Key can be
removed.
RIGHT HANDLEBAR CONTROLS
Engine Stop Switch
The two position engine stop switch is next to the throttle grip. When the switch is in the
(RUN) position, the engine will operate. When the switch is in the (OFF) position, the
engine will not operate. This switch is intended primarily as a safety or emergency switch and
should normally remain in the (RUN) position.
NOTE:
If your motorcycle is stopped with the ignition switch ON and the engine stop switch OFF,
the headlight and taillight will still be on, resulting in battery discharge.
Starter Button
The starter button is below the engine stop switch. When the starter button is pressed, the
starter motor will crank the engine. If the engine stop switch is in the (OFF) position, the
starter motor will not operate.

Honda ST1100 1996+ Specifications

General

Compression Ratio	10.0:1
Cooling System	Liquid-cooled
Transmission	5-speed
Final Drive	Shaft
Rear Tire	160/70-17
Engine Type	Liquid-cooled, 4-stroke, 90° V4
Ignition	Digital transistorized
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock with adjustable preload
Front Brakes	Dual hydraulic discs
Rear Brakes	Single hydraulic disc
Wheelbase	61.4 in (1560 mm)
Fuel Capacity	28.0 L (7.4 US gal)
Fuel System	Carburetor
Front Tire	110/80-18
Seat Height	805 mm (31.7 in)
