Honda ST1100 1996+ User Manual

- Copyright for this owners manual only ©2011 LIFRASCHAL -
53
TOOL KIT
The tool kit is in the right fairing pocket. Open the right fairing pocket. Some roadside repairs,
minor adjustments and parts replacement can be performed with the tools contained in the kit.
 Spark plug wrench
 10 x 12 mm Box end wrench
 14 mm Box end wrench
 24 mm Box end wrench
 27 mm Box end wrench
 8 mm Open end wrench
 10 x 12 mm Open end wrench
 14 x 17 mm Open end wrench
 Pliers
 Screwdriver handle
 Screwdriver
 Pin spanner
 Pin spanner grip
 5 mm Hex wrench
 6 mm Hex wrench
 Feeler gauge 0.5 mm (Model equipped with CBS/ABS/TCS)
 Tool bag
SERIAL NUMBERS
The frame and engine serial numbers are required when registering your motorcycle. They
may also be required by your dealer when ordering replacement parts. Record the numbers
here for your reference. The frame number is stamped on the right side of the steering head.
The engine number is stamped on the rear of the lower crankcase behind the oil pan.

Honda ST1100 1996+ Specifications

General

Compression Ratio	10.0:1
Cooling System	Liquid-cooled
Transmission	5-speed
Final Drive	Shaft
Rear Tire	160/70-17
Engine Type	Liquid-cooled, 4-stroke, 90° V4
Ignition	Digital transistorized
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock with adjustable preload
Front Brakes	Dual hydraulic discs
Rear Brakes	Single hydraulic disc
Wheelbase	61.4 in (1560 mm)
Fuel Capacity	28.0 L (7.4 US gal)
Fuel System	Carburetor
Front Tire	110/80-18
Seat Height	805 mm (31.7 in)
