30
Headlight Switch (Except U type)
The headlight switch has three positions, , and "OFF" marked by dot.
 : Headlight, taillight, position light and meter lights on.
 : Position light, taillight and meter lights on.
 OFF (dot): Headlight, taillight, position light and meter lights off.
LEFT HANDLEBAR CONTROLS
The controls next to the left handlebar grip are:
Headlight Dimmer Switch
Select (HI) for high beam, (LO) for low beam.
Horn Button
Press the button to sound the horn.
Turn Signal Switch
Move the switch to (L) to signal a left turn, to (R) to signal a right turn; the appropriate
turn signal and indicator will blink. Push to turn signal off.
Passing Light Control Switch
When this switch is pressed, the headlight flashes on to signal approaching cars or when
passing.

Honda ST1100 1996+ Specifications

General

Compression Ratio	10.0:1
Cooling System	Liquid-cooled
Transmission	5-speed
Final Drive	Shaft
Rear Tire	160/70-17
Engine Type	Liquid-cooled, 4-stroke, 90° V4
Ignition	Digital transistorized
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock with adjustable preload
Front Brakes	Dual hydraulic discs
Rear Brakes	Single hydraulic disc
Wheelbase	61.4 in (1560 mm)
Fuel Capacity	28.0 L (7.4 US gal)
Fuel System	Carburetor
Front Tire	110/80-18
Seat Height	805 mm (31.7 in)
