Honda ST1100 1996+ User Manual

- Copyright for this owners manual only ©2011 LIFRASCHAL -
63
Engine
SPARK PLUGS
Refer to Maintenance Precautions on. Recommended plugs:
 Standard: CR8EH-9 (NGK), U24FER-9 (NIPPONDENSO)
 For extended high speed riding: CR9EH-9 (NGK), U27FER-9 (NIPPONDENSO)
1. Remove the air duct/maintenance cover. (Right side shown; left side similar).
2. Disconnect the spark plug caps.
3. Clean any dirt from around the spark plug bases.
4. Remove the spark plugs.
5. Visually inspect the spark plug electrodes for wear. The center electrode should have
square edges and the side electrode should not be eroded.
6. Discard the spark plug if there is apparent wear or if the insulator is cracked or
chipped.
7. Make sure the spark plug gap is 0.8-0.9 mm (0.031-0.035 in) using a wire-type feeler
gauge. If adjustment is necessary, bend the side electrode carefully.
8. With the plug washers attached, thread the spark plugs in by hand to prevent cross-
threading.
9. Tighten the spark plugs 1/2 turn with a spark plug wrench to compress the washers. If
you are reusing a plug, it should only take 1/8-1/4 turn after the plug seats.
10. Reinstall the spark plug caps.
11. Reinstall the air duct/maintenance cover.

Honda ST1100 1996+ Specifications

General

Compression Ratio	10.0:1
Cooling System	Liquid-cooled
Transmission	5-speed
Final Drive	Shaft
Rear Tire	160/70-17
Engine Type	Liquid-cooled, 4-stroke, 90° V4
Ignition	Digital transistorized
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock with adjustable preload
Front Brakes	Dual hydraulic discs
Rear Brakes	Single hydraulic disc
Wheelbase	61.4 in (1560 mm)
Fuel Capacity	28.0 L (7.4 US gal)
Fuel System	Carburetor
Front Tire	110/80-18
Seat Height	805 mm (31.7 in)
