Honda SUBWOOFER KIT - Page 4

4 of 11 AII 30529 (0509) © 2005 American Honda Motor Co., Inc. - All Rights Reserved.
12. Remove the three seat track end covers, then
remove the four bolts that secure the front driver’s
seat.
M/T Vehicle:
13. Remove the driver’s kick panel by pulling it out
toward you to release the two clips, and then
back to release the five tabs. Take care not to
damage the clips.
A/T Vehicle:
14. Gently slide the front driver’s seat toward the
center of the vehicle. Be careful not to pull the
yellow SRS harness too tight.
15. Reach inside the vehicle, and pull out on the
bottom of the left front door sill trim to release the
two clips; then lift it up to release the three clips,
then remove the trim.
2N21020
Y
DRIVER’S
KICK PANEL
CLIPS (2)
TAB
TAB
4628010
K
BOLTS (4)
FRONT
DRIVER’S SEAT
SEAT
TRACK END
COVERS (3)
4628020
K
FRONT
DRIVER’S SEAT
BOLTS (4)
SEAT
TRACK END
COVERS (3)
4728040
M
LEFT FRONT
DOOR SILL TRIM
CLIPS (5)
