Tyre Puncture u Removing Wheels
82
#
Front Wheel
Removal
1.
Place your vehicle on its centre stand on a
firm, level surface.
2.
Support your vehicle securely and raise the
front wheel off the ground using a
maintenance stand or a hoist.
3.
Remove the speedometer cable by
pushing the tab.
4.
Remove the front axle nut.
5.
Remove the front axle shaft, front wheel,
speedometer gearbox and side collar.
u Avoid getting grease, oil, or dirt on the
disc or pad surfaces.
u Do not pull the brake lever while the
front wheel is removed.
Front axle nut
gearbox
Tab
Front axle shaft
