Check the brake cable for kinks or signs of
wear. If necessary have it replaced by your
dealer.
Lubricate the brake cable with a
commercially available cable lubricant to
prevent premature wear and corrosion.
Make sure the brake arm, spring and fastener
are in good condition.
Adjusting the Rear Brake Pedal
Freeplay
Make sure the cut-out on the adjusting nut is
seated on the brake arm pin when adjusting
the freeplay.
If proper adjustment cannot be obtained by
this method, see your dealer.
20181207113539_32KVMC000_eng_BOOK Page 63 Friday, December 07 2018 11:40:26 JST
Brakes u Adjusting the Rear Brake Pedal Freeplay
Maintenance
60
Brake arm pinAdjusting nut
