Once setup is completed, if you need to
change more settings go to the advanced
menu. To access the advanced menu
press for 5 seconds.
Set Up and
configuratio
6
Wiring Diagrams
In the advanced menu the following
settings can be adjusted:
1) Touch to begin
setting up the thermostat.
2) Select your language.
3) Set the clock format,
time and date.
4) Touch to finalise setup.
( to setup using the App is
currently unsupported)
https://hwllhome.co/uk-wiring
For other wiring
diagrams visit:
* See boiler specifications for correct terminals
A) Basic 230V boiler
Boiler
Receiver Box
B) Combi boiler
Receiver Box
T1 T2
Boiler*
C) OpenTherm boiler
D) Two-port zone valve or S-plan
Receiver Box
V4043
LANGUAGE
OPENTHERM
CYCLE RATE
MINIMUM ON TIME
HEAT RANGE
SCHEDULE OPTIONS
OPTIMISE
CLOCK
LOW LOAD CONTROL
TEMPERATURE OFFSET
BINDING
RESET
FAILSAFE
English
6
ON 0 = off, 1 = on
OFF
-
-
-
0 = off, 1 = on
0.0ºC 1.5 ºC to 1.5ºC
Bind , check RF and clear bind.
Factory, schedule, WiFi and HomeKit reset
Clock format: 1 = 12h, 2 = 24h
Setup time and date
1 minute
3, 6, 9 or 12
Daily
Opt. start OFF
Opt. stop OFF
Opt. start: 0 = off, 1 = on, 2 = Delayed start
Opt. stop: 0 = off, 1 = on
Format: 24h
Time: --:--
Date: 01/09/16
1, 2, 3, 4 or 5 minutes
Min = 5.0ºC
Max = 35.0ºC
1 = Daily schedule, 2 = 5+2 days schedule
Min: 5ºC to 21ºC, Max: 21ºC to 35ºC
Menu Item Default Options
0 = English, 1 = Français, 2 = Español
3 = Deutsch, 4 = Nederlands, 5 = Italiano
OpenTherm boiler data when available
© 2020 Resideo Technologies, Inc. All rights reserved.
The Honeywell Home trademark is used under license from Honeywell International Inc.
This product is manufactured by Resideo Technologies, Inc. and its affiliates.
Pittway Sarl, Z.A. La Pièce 4,
1180 Rolle, Switzerland
Country of origin : UK
***SETUP****
SETUP
**LANGUAGE**
*CLOCK
SETUP
SETUP
CONFIGURE W
AM
PM
AM
PM
AM
PM
*1234
1 2 3 4 5 6
*****230****
5 sec
Receiver Box
Boiler*
T1 T2
For security reasons:
Route this wiring
through conduit or
in the wall so it is not
accessible.
