Chapter 1 Introduction
3 Pnet I/F Module 2MLL-PSRA, 2MLL-PMEA, 2MLL-PMEB User’s Guide R240
Honeywell January 2019
1.3.3 Slave Device
The Pnet I/F module can be connected with Smart I/O series and available product list is as follows.
(1) Master module
Item
Connection
cable
Model
Product code
contents
Remark
Master
module
Twisted pair
(Electricity)
2MLL-PMEA
47200001
Profibus DPv0
Sycon
2MLL-PMEC
47200103
Profibus DPv0
ProfiCon
2MLL-PMEB
47200180
Profibus DPv1
(2) Slave module
Item
Connection cable
Model
Product code
contents
Remark
Slave
module
Twisted pair
(electricity)
MPL-D22A
47060007
DC input 16 points
Fixed type, 9-pin
communication
connector
MPL-D24A
47060009
DC input 32 points
MPL-TR2A
47060008
TR output 16 (0.1A, Sink)
MPL-TR4A
47060010
TR output 32 (0.1A, Sink)
MPL-RY2A
47060011
Relay output 16
MPL-DT4A
47060012
DC input 16/ TR output 16
MPL-D22C
47060046
DC input 16
Removable type, 9-pin
communication
connector
MPL-D24C
47060047
DC input 32
MPL-TR2C
47060048
TR output 16 (0.5A, Source)
MPL-TR4C
47060049
TR output 32 (0.5A, Source)
MPL-RY2C
47060051
Relay output 16
MPL-DT4C
47060050
DC input16/ TR output 16
MPL-TR2B
47060059
TR output 16 (0.5A, Source)
Fixed type, 9-pin
communication
connector
MPL-TR4B
47060058
TR output 32 (0.5A, Source)
MPL-DT4B
47060060
DC input16/ TR output 16
MPL-TR2A1
47060084
TR output 16 (0.5A, Sink)
MPL-TR4A1
47060076
TR output 32(0.5A, Sink)
MPL-DT4A1
47060078
DC input 16/ TR output 16
MPL-TR2C1
47060085
TR output 16 (0.5A, Sink)
Removable type, 9-pin
communication
connector
MPL-TR4C1
47060077
TR output 32 (0.5A, Sink)
MPL-DT4C1
47060079
DC input 16/ TR output 16
MPL-AV8C
47060123
Analog voltage input, 8 channels
MPL-AC8C
47060124
Analog current input 8 channels
MPL-DV4C
47060125
Analog voltage output, 8
MPL-DC4C
47060126
Analog current output, 8
MPL-BSSA
47060130
Expansion type Pnet I/F module
Module for expansion
type Pnet I/F module
2MLL-PSRA
47200128
Pnet Remote I/F module
Remote I/F module
[Table1.3.1] Pnet I/F module product list (Smart I/O)
Note
1) Fixed type: The product whose I/O terminal block is fixed at the module
2) Removable type: The product whose I/O terminal block can be removed
