HONEYWELL MODEL 700/800 SIGNAL PROCESSOR AND VIEWING HEAD
21 66-2069EP—08
Fig. 10. Models S702 and S706 Viewing Heads.
Fig. 11. Models S802 and S806 Viewing Heads.
M34284B
7-11/16
(195)
6
(153)
1-1/2
(38)
13/32 (10)
1-1/8
(29) DIA
1/2 NPT FOR SIGHTING PIPE
HEX 1-1/2 (38) ACROSS FLATS
1-3/4 (45) DIA MOUNTING BLOCK
1/4 NPT FOR PURGE AIR
