HONEYWELL MODEL 700/800 SIGNAL PROCESSOR AND VIEWING HEAD
23 66-2069EP—08
Fig. 13. Model 700ACSP Signal Processor.
APPROVED
M34851A
5-1/2
(139)
2-29/32 (74)
MODEL 700AC
3-1/4 (83)
1/4
(6)
35MM DIN RAIL
DIN RAIL RELEASE
C
L
RS-422 WIRING
RELAY CONNECTIONS
