HONEYWELL MODEL 700/800 SIGNAL PROCESSOR AND VIEWING HEAD
25 66-2069EP—08
Fig. 16. IR Viewing Head Location
Fig. 17. UV Viewing Head Location
BURNER NOZZLE
CENTERLINE
DETECTOR IN POOR
SIGHTING POSITION
DETECTOR IN GOOD
SIGHTING POSITION
(PARALLEL SIGHTING)
LOW FREQUENCY
FLICKER ZONE
HIGH FREQUENCY
FLICKER ZONE
M33286B
UV VIEWING
HEAD SIGHTED
ON UV ZONE
BURNER NOZZLE
CENTERLINE
UV RADIATION
ZONE
