Honeywell 854 ATG Series - Freeze and Block Command Usage

Operation
P
age 28
Function
switch L
Additional display and function of other switches
1
st
Display configuration
R display test (blank test / dark test)
U display contrast up
D display contrast down
2
nd
Display format toggle (formats A - K)
U previous display format
D next display format
3
rd
NOVRAM item view (all items)
R fast forward
U previous item
D next item
4
th
Error list view (item EP)
R fast forward
U previous error
D next error
5
th
System configuration (items: GT, TA, TC, TH, TI, TS, WM)
U previous item
D next item
6
th
Diagnostic view (items: 00, 03, EI, 0S, 0T, EJ, EP, FS, FH, FM, FT, FX, PF, XS, LC)
U previous item
D next item
7
th
Test gauge
R test gauge
U lock test
D unlock
The steps of switch L can only be followed in the sequence as given in the table above.
Display scroll
The XPU-2 display can be configured to scroll automatically through all display formats.
This is done by setting item 3Z to enable.
Item Name Description
W2= Protection level 2 Enter protection level 2 password.
3Z= Toggle display format With this item, the toggle display format function (display scroll) can be
enabled or disabled. When enabled, all display formats are shown for
approximately 2 seconds.
E : enable toggle display format
D : disable toggle display format
EX Exit Exit protection level.
